IPG HIGH POWER LASER SOURCE -OUTPUT POWER 8000W (YLS-U/CUT SERIES)


IPG

YLS-U/CUT Series is a High-Power Laser Source have been developed specifically for demanding cutting applications. Supplied in the smallest form factor available on the market, these lasers can be easily integrated within cutting machines. IPG world-leading industrial pump diode packaging technology and are the only hermetically sealed mid-power lasers on the market that can operate in extremely high humidity environments up to 90% relative humidity.



WORLD FAMOUS BRAND

YLS-U/CUT Series High Power Fiber Laser Source with a powerful cutting ability with Stainless Steel, Aluminum, Carbon Steel and other Metal Materials.



LONG SERVICE LIFE

The world leading IPG Laser Source has stable performance, the service can reach 100000 Hours and overall quality of the equipment can be guaranteed safely.



STABLE CUTTING PERFORMANCE

Fiber Laser Source can produce excellent beam quality, finer cutting lines higher working efficiency and better machining quality. Fully closed constant temperature working environment makes Laser Source more effective to ensure stable operation.



THE HIGHEST RELIABILITY

IPG’s unique combination of technologies results in a highly reliable laser system that outperforms any traditional laser technology including disc, rod or CO2 lasers. IPG is compact, robust fiber lasers have the longest diode lifetimes, require minimal maintenance and have the lowest down time.

Quick info

SKU: 6094647777-1-1-1-2-2-1-1-1 Categories: ,
GET A QUOTESpecs pdf download

Description

Optical Characteristics
Central Wavelength Range , nm: 1070 ±5
Mode of Operation: CW/Modulated
Modulation Frequency, kHz: 0-5
LASER POWER: 8000W
Power Tunability, %: 10-100
Power Stability**, %: ± 2
Optical Noise***, % RMS: <2, typ.1
Output Fiber Core Diameter***, μm: 50, 100, 150, 200
: <2.2 @ 50 μm, 2.0 typ., <4.0 @ 100 μm, 3.3 typ.,
Beam Parameter Product, mm × mrad: <6.0 @ 150 μm, 5.0 typ., <8.0 @ 200 μm, 6.0 typ.
* ** Over 4 hours, T=const
*** A direct feeding fiber terminating in either an HLC-8 (QBH-type) or LCA (QD-style) connector in standard lengths of up to 30 meters. Maximum delivery fiber length is 20 m @ 50 μm. Custom connectors and fiber length are available.
General Characteristics
Cabinet Dimensions (W×D×H): 430 × 804 × 900 mm
Cabinet Weight: <250 Kg.
Supply Voltage, 3-phase, VAC: 400-480
Wall-plug Efficiency, %: >40
