POWER PRESS JD23- 25 TON


ROOY

MACHINE DESCRIPTION

Power Press Machine is used for cutting, shaping, blending and pressing any metal sheet into required shape. This is a multi-purpose machine used to shape the metal sheet to be used for getting the desired shape of the parts to be used in electric and electronic appliances, automobile industry and metal manufacturing. The power press machine has revolutionized this process by adding force and accuracy in the operation of pressing.

Quick info

SKU: 2441668114 Categories: ,
GET A QUOTESpecs pdf download

Description

POWER PRESS MACHINE
ModelJD23-25
Brand Name“ROOY”
Nominal Force 250 KN
Stroke under Nominal Force 4 mm
Slide Stroke10-70 mm
Number of Stroke70 Times /min
Max. Die set Height200 mm
Die Height Adjustment40 mm
Distance from slide block center to the frame200 mm
Worktable Size (FB x LR)320 x 500 mm
Worktable hole diameterɸ200 mm
Thickness of bolster50 mm
Slide Block Size (FB x LR)170 x 230 mm
Size of the handle hole (Dia. x Depth)ɸ40 x 60mm
Distance between columns 240mm
Motor Power 3 kw (Y100L2-4)
Overall dimension1130 x 900 x 2050 mm
Weight2500 kg.
