Brand Name | : “HYPERTHERM” |
Input voltages | : 200–480 V, 1-PH, 50/60 Hz |
| : 200–600 V, 3-PH, 50/60 Hz |
Kilowatt output | : 12.2 kW |
| : 200/208/240/480, |
| : 1-PH 70/68/58/29 A @ 12.2 kW |
Input current | : 200/208/240/480/600 V, |
| : 3-PH 42/40/35/18/17 A @ 12.2 KW |
Output current | : 25–85 A |
Rated output voltage | : 143 VDC |
| : 60% @ 85 A, 230–600 V, 3-PH |
| : 60% @ 85 A, 480 V, 1-PH |
| : 50% @ 85 A 240 V, 1-PH |
Duty cycle @ 104° F | : 50% @ 85 A, 200–208 V, 3-PH |
| : 40% @ 85 A, 200–208 V, 1-PH |
| : 100% @ 66 A, 230–600 V, 1/3-PH |
Open circuit voltage (OCV) | : 305 VDC |
Dimensions with handles | : 483 mm D; 233 mm W; 430 mm H (19″ D; 9.2″ W; 17″ H) |
Weight w/7.6 m (25′) torch | : 32 kg (67 lbs.) |
Gas supply | : Clean, dry, oil-free air or nitrogen |
Optimum inlet gas pressure | : 7.6–8.3 bar (110–120 psi) |
Minimum inlet gas pressure | : 5.2 bar (75 psi) |
Recommended inlet gas flow rate | : Cutting: 210 I/min @ 5.9 bar (450 scfh, 7.5 scfm @ 85 psi) |
| : Gouging: 210 I/min @ 4.8 bar (450 scfh, 7.5 scfm @ 70 psi) |
Input power cable length | : 3 m (10′) |
Power supply type | : Inverter–IGBT |
Engine drive requirement | : 20 kW for full 85 A output |
Brand New | : USA |
|
CUTTING CAPACITY |
Capacity | Thickness | Cut speed |
| 25 mm (1″) | 500 mm/min (20 ipm) |
Recommended | 32 mm (1-1/4″) | 250 mm/min (10 ipm) |
Severance (hand cutting) | 38 mm (1-1/2″) | 125 mm/min (5 ipm) |
Pierce* | 22 mm (7/8″) | |
*Pierce rating for handheld cutting, or mechanized cutting with programmable torch height control. |
|
MAXIMUN REMOVAL GOUGING: |
Capacity | Metal removal rate | Gouge profile |
Typical gouge | 8,2 kg (18.2 lbs.) per hour | 3,5 mm D x 6,6 mm W (0.14″ D x 0.26″ W) |
