  /    /  HYPERTHERM POWER SOURCE, CNC PLASMA CUTTING  /  POWERMAX 125

POWERMAX 125


HYPERTHERM

Hypertherm is working  tirelessly on innovations to help meet market needs with a history of delivering industry-leading cutting technology and look at the future with possibility. With engineering team that works together to optimize the performance of your system across the Hypertherm product line. Hypertherm’s plasma cutting solutions range from powerful, portable Powermax® systems for cutting and gouging to industry-leading HyPerformance® mechanized cutting systems, as well as LongLife® heavy-duty production tools, and the diesel-driven Freedom™ system.



Delivering maximum power and performance for air plasma, the Powermax125® plasma system cuts thick metals fast. Portable, heavy-duty 38 mm (1-1/2”) plasma system maximizes uptime and productivity in handheld and mechanized cutting and gouging operations. Able to make short work of the toughest cutting and gouging jobs, the system offers a 100% duty cycle, a 25 mm (1″) mechanized pierce capability, and fast gouging metal removal. It also gives you the latest technological innovations, such as Smart Sense™ technology to automatically adjust the gas pressure. Eleven Duramax® Hyamp™ torch styles provide versatility for hand cutting, portable automation, X-Y table cutting, extended reach cutting, and robotic cutting and gouging.



Quick info

SKU: 6094647777-1-1-1-1 Categories: ,
GET A QUOTESpecs pdf download

Description

Input Voltages 400 V, 3-PH, 50/60 Hz
Input Current400 V, 3-PH, 50-60 Hz, 36 A
Output Current30 - 125 A
Rated Output Voltage175 VDC
Duty Cycle @ 40°C (104°F)100% @ 125 A, 400 V, 3-PH
Dimensions with Handles592 mm D; 274 mm W; 508 mm H
Weight with Torch49 kg
Gas SupplyCuttingAir, N2, F5
GougingAir, N2, F5
Recommended Flow Rate and PressureCutting260 L/min @5.9 bar
Gouging212 L/min @4.1 bar
Torch Lead LengthsHandheld7.6, 15.2, 22.8, 45.7 m
Mechanized4.5, 7.6, 10.7, 15.2, 22.8, 45.7 m
Motor Generator53.6 kVA, 40 KW
Cutting Capacity :
CapacityCutting ThicknessCutting speed
Recommended38 mm457 mm/min
44 mm250 mm/min
Severance (hand cutting) 57 mm125 mm/min
Pierce 25 mm
