Hydraulic Shearing Machine QC12Y-12mmx3200mm


VOX

Vox’ main products are CNC Hydraulic Press Brake, Hydraulic Press Brake and Shearing machine. Vox offers quality Hydraulic Press Brakes and Hydraulic Shearing machine that provides simplifies and easily accessible controls for optimum operator efficiency and output.

Quick info

Get A QuoteSpecs PDF Download

Description

HYDRAULIC SHEARING MACHINE
Model NoQC12Y - 12mm x 3200mm
Brand Name“VOX”
(Joint Venture with France Co)
With E21S NC Controller
Shearing thickness12 mm
Shearing width3200 mm
Strength of Sheets450 N/mm²
Shearing Angle1°45’
Back gauge Range600 mm
Number of Stroke12 min-¹
Length of Blade3460 mm
Height of the Work Table740 mm
Main Motor (4-B5)TypeY180M-4
Power18.5 Kw
Speed1460 r/min
Gear PumpTypeCP1-040-P-10R
Nominal Displacement40 ML/r
Pressure25 MPa
Overall dimension ( LxWxH )4050 x 2100 x 1900 mm
Net Weight10500 kg.



  • Schneider electrical elements with CE standard electrical components and thermal overload protection, big chain lockable. Main power switch, E21 NC Controller with inverter.
  • Rexroth main valve, Siemens motor and Sunny gear pump.
  • NOK SEAL RING, CHIP-SLEEVE-PIPE CONNECTION, EMERGENCY STOP, STANDARD UPPER AND LOWER TOOLING, IRON PALLET IN FOUR CORNERS.
  • Illuminated cutting line.
  • Sides and rear guards-covers, side guard fence with limited switch
  • Cantiler arm with stainless steel.
  • Foot pedal control
  • Manual adjustable the gap of the blades
  • Sheet support with ball transfer roller table
  • Bite type tube fittings
  • Automatically dropping system
