Pipe Notching – TT90


CESURBEND

Pipe notching machine is manually operated with the blade notching up to 90° notch to one section of the tube. The Pipe notching machines also called “abrasive notcher” or “tube notcher” is machines that work by abrasive belts. Pipe notching machines are designed to prepare tube corner joints for welding process.

  • Ø19, Ø21, Ø25, Ø32, Ø38, Ø42, Ø48, Ø52, Ø60, Ø76 rolls standard for TT90

Quick info

SKU: 5653123220 Categories: ,
Get A QuoteSpecs PDF Download

Description

Model: TT-90
Clamp Capacity: Ø16- Ø90 mm
Notching Capacity: Ø16- Ø90 mm
Belt Size : 100 x 1250 mm
Motor Power: 2.2 kw
Mandrel Diameters: Ø19, 21, 25, 32, 38, 42, 48, 52, 60, 76
Voltage : 380V / 3Phase / 50Hz
Dimension (L x W x H): 1200 x 600 x 1150 mm
Weight: 180 kg
Made in: Turkey
