Four-roller Plate Rolling Machine W12-30×3100


WEIDA

Weida is a large-scale joint-stock enterprise with the right to import and export of milling machines , CNC gantry milling machines , universal milling machines, CNC boring and milling machines, etc. It has a milling machine technology development center, an information data processing center, product supervision and testing center and a measurement room. CAD and ERP are used for new product development and enterprise information management.



Overview:

This machine is four-roller plate rolling machine, top roller  are main drive and do rotation movement, lower roller makes up-down movement to make the plate  can get the frication along with length direction, two side rollers makes Up-down movement which is an angel with straight line, which can make the steel plate get the needed plastic deformation.

Quick info

Get A QuoteSpecs PDF Download

Description

Model NoW12-30×3100
Max width3100mm
The length of working roller3200mm
Max thickness ( central)T30*B3100*φmin1200(σs≤245Mpa)mm
Max thickness (end)T25*B3100*φmin1200(σs≤245MPa)mm
Top roller diameterΦ510 mm
Lower roller diameterΦ460 mm
Side roller diameterΦ390 mm
Rolling speed About 3.5 m/min
Main motor power37 kW
Max working pressure of hydraulic system19.5 MPa
