HYDRAULIC PRESS HD/160 Ton


HIDROLIKSAN

Workshop Type Hydraulic Presses HD160 Ton Motor Operated

Hidroliksan continues to manufacture hydraulic presses and is is proud to able to respond the needs of the following sectors which are automotive, agriculture, metal forming, recycling and many others they  need to compression  in their  production.



MACHINE DESCRIPTION

Workshop-Type Presses are standard-type presses, as well as measured according to customer purpose. Workshop-type presses can be manufactured up to 1000 tons in automatic and manual as optional. All Hidroliksan Workshop Presses comply with the strictest regulatory requirements, meeting the European CE standards. Each Hidroliksan Workshop Press includes a comprehensive manual, supporting our end users in use and maintenance of our products. Hidroliksan Workshop Type Presses are used mostly in repair and maintenance workshops for the small bending, punching, straightening, detruding / extracting (removing).

Quick info

SKU: 6661276491 Categories: ,
GET A QUOTESpecs pdf download

Description

HYDRAULIC PRESS
Model No. HD/160 Ton
Brand NameHIDROLIKSAN
Pressing Power1600 kN
Operating Pressure400 bar
Stroke (Course)400 mm
ELECTRIC MOTOR
Motor5.5kW
Power7.5Hp
Motor revolution1500 Rev/min
Voltage380 V
Frequency50-60Hz
HYDRAULIC SYSTEM
Pump vol. rate15 Lit/min
Tank volume40 lt.
Oil to be filled36 lt
OPERATING CONDITIONS
Landing speed6.2 mm/s
Return speed9.8 mm/s
CRITICAL DIMENSIONS
Inner diameter of the cylinder225 mm
Ram diameter135 mm
A. Height2500 mm
B. Side width btn st1000 mm
C. Front width btn st1400 mm
D. Inner width1100 mm
E. Side width350 mm
H. Max Work capacity900 mm
Weight1300 kg
