LINEAR&LOW RIB ROLL FORMING MACHINE RF10-100-1160


GMG

CUTTING:

  1. Cutting motor: The main machine    automatically stops   and then cutting.  After the cutting, the main machine will automatically start.
  2. Material of blade: GCR12 with heat treatment
  3. Length measuring: Automatic length measuring
  4. Tolerance of length: 3m+-1.5mm
  5. Roller Stations : 9 stations
  6. Roller Material : 45Cr forge steel, CNC lathed, hard chrome coated



CONTROL BOX: PANASONIC BRAND

  1. Voltage, Frequency,   Phase:   380   V,   50   Hz,  3Phase   (this  is can depend  on customer request)
  2. Automatic length measurement
  3. Automatic quantity measurement
  4. Computer used to   control   length & Machine will automatically cut to length and stop when required quantity is achieved
  5. Length inaccuracy can be amended
  6. Control panel: Bu_on‐type switch and touch
  7. Unit of length: mm (switched on the control panel)

Quick info

SKU: 4786422646 Categories: ,
GET A QUOTESpecs pdf download

Description

ModelRF10-100-1160
Rolling Speed0-10m/min (not include cutting time)
Rolling Thickness0.4-0.8 mm
De- Coiler5 tons manual de-coiler
Tolerance3m+-1.5mm
Roller Stations9 stations
Roller Material45Cr forge steel, CNC lathed, hard chrome coated
Shaft Material and Dia.¢65mm, material is 45# forge steel
Main Motor Power3 Kw
Electric Source380V, 50HZ,3 phase
Hydraulic Station Power4kw
Control SystemPLC (Panasonic)
Hydraulic Pressure10Mpa
Material Of CuttingCr12Mov ,quenching 58-62℃
Way Of Drive1 inch single chain
Size of the machine (LxWxH)2.2m x 1.5m x 1.5m
