Hydraulic CNC Press Brake – PB1332


YANGLI

Hydraulic CNC Press Brake | Precision Metal Bending Solutions

Boost your metal fabrication capabilities with our advanced hydraulic CNC press brake. Designed for precision and efficiency, this machine provides exceptional control for bending and shaping metal sheets. Featuring a powerful hydraulic system and innovative CNC technology, our press brake delivers consistent, high-quality results, even for complex projects. Ideal for use in the automotive, aerospace, and construction industries, our hydraulic CNC press brake meets the rigorous demands of modern manufacturing. Learn how our press brake can enhance your production process, minimize material waste, and increase productivity. Contact us today to discover more about our hydraulic CNC press brake and how it can benefit your business.

Quick info

Get A QuoteSpecs PDF Download

Description

CNC HYDRAULIC PRESS BRAKE MACHINE (4 Axis + CNC Crowning)
Model NoPB1332 (130Ton x 3200)
With DELEM DA-53T CONTROL SYSTEM
Nominal Force 1300 KN
Bending Length 3200mm
Distance Between Frames 2700 mm
Throat Depth 410 mm
Stroke215 mm
CNC Axes Y1, Y2, X, R, V
Main Servo Motor Power9 KW (Rated)
Worktable Height800 mm
Worktable Width 200 mm
Max. Shut Height520 mm
Idle Speed of Slide 180 mm/s
Working Speed of slide10 mm/s
Ram Returning Speed 130 mm/s
Backgauge StrokeX: 600mm; R: 200mm
Backgauge AccuracyX: ±0.10mm; R: ±0.50mm
Backgauge SpeedX: 400mm/s; R: 200mm/s
Backgauge Power X: 1KW; R: 1KW
Voltage 380V/50Hz/18A
Oil Tank Capacity 300 Ltr.
Machine Dimension (L x W x H) 3600 x 1650 x 2850mm
Weight 8000 kg. (8 Ton)

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.

Press Brake Tonnage Calculator (metric)

You can calculate press brake tonnage by input below required data.
If you are a manufacturer or a sheet metal processing factory that needs to buy new Press Brake Machine, you can refer to the Press Brake Tonnage Calculator for calculating the required bending tonnage. By using the Press Brake Tonnage Calculator, you only need to enter the Sheet Metal Thickness, Bending Length, and our recommended vee opening width then the calculator will show the required bending force.
