STUD & TRACK FORMING MACHINE


GMG

MACHINE COMPONENTS:

  • Decoiler
  • Roll Forming Machine
  • Hydraulic Cutting Machine
  • Control System
  • Product Table

Quick info

SKU: 5513627950 Categories: ,
GET A QUOTESpecs pdf download

Description

1.5T MANUAL DECOILER
Coil inner diameterφ450mm-φ530mm
Coil outer diameterφ1300mm
Material width available20mm-300mm
Max carrying capacity1500kg
ROLL FORMING MACHINE
Shaft diameter50mm
Roller MaterialCr12
Stations14 stations
TransmissionGear wheel
Forming speed15m/min (5-6pcs/min)
Motor4kw
StructureIndependent stand
HYDRAULIC CUTTING MACHINE
Material of blade or moldCr12 steel
Power4 kw
Flying cut and punch
CONTROL SYSTEMDelta PLC, touch screen, full auto
PRODUCT TABLE
One set of product table3m
